RE2300 / RE2304

Emergency Relay Valve, Trailer
SUNDOZ NO:RE2300
ORG NO:971 002 300 0

SUNDOZ NO:RE2300
ORG NO:971 002 301 0

SUNDOZ NO:RE2304
ORG NO:971 002 304 0

REPAIR KIT
SUNDOZ NO:RE2300.K
ORG NO:971 002 008 2

SUNDOZ NO:RE7000 = ORG NO:971 002 700 0
WITH BYPASS VALVE

RE2300:
1. Max. operating pressure: 8.5 bar
2. Predominance : adjustable: 0 to 1
3. Port 1: M 22x1.5
4. Port 2: M 22x1.5
5. Port 1-2: M 22x1.5
6. Port 4: M 16x1.5

RE2301:
1. Max. operating pressure: 8.5 bar
2. Predominance : adjustable: 0 to 1
3. Port 1: M 22x1.5
4. Port 2: M 22x1.5
5. Port 1-2: M 22x1.5
6. Port 4: M 16x1.5

RE2304:
1. Max. operating pressure: 8.5 bar
2. Predominance : adjustable: 0 to 1
3. Port 1: M 22x1.5
4. Port 2: M 22x1.5
5. Port 1-2: M 22x1.5
6. Port 4: M 22x1.5
