1. Operating pressure: 5 ... 8 bar 2. Type: Proportional valve 3. Port threads: M 12x1.5 4. Port 4: M 27x1 5. Duty cycle: Continuous (100%) 6. Protection: IP 67 7. Nominal diameter: 4/2.5 8. Rated current: 0.57
SUNDOZ NO:SA1335961 ORG NO:472 250 000 0 1. 117024-2 ERF 2. 125736 Leyland DAF 3. 1335961 SC 4. 1505432 DAF 5. 440 719 9 Dimetal 6. 4810 12 341 1114 NATO 7. 653877-3 Dennis 8. 655586 Dennis 9. 664 429 70 82 DaimlerChrysler 10. 79 10058 0415 MAN 11. 79100 580415 Steyr 12. 9846 5149 Iveco
